Sale!

Wika Instruments 2.5" Type 213.40 5,000PSI Gauge – 7/16-20 SAE LM Forged Brass

Original price was: $114.95.Current price is: $80.47.

SKU: Wika Instruments WBB231548 Categories: Dial Pressure & Vacuum Gauges, Pressure & Vacuum Gauges, Testing & Inspection Instruments Tags: 213.40, Acrylic, Brass Copper Alloy, Glycerine, Standard, Tools & Instruments, Wika Instruments, Yes

Buy with Confidence, Get Quality
Your happiness, our mission.
No-Questions-Asked Returns
Excellent customer service online in a timely manner

Wika 2.5 Type 213.40 5,000 PSI Gauge – 7 / 16-20 SAE LM Forged Brass

WIKA Type 21X.40PM gauges are designed to fit existing paper machine panels. Each gauge is hermetically sealed to prevent moisture from entering during washdown. The hermetic seal makes this gauge liquid fillable for high vibration or pulsation applications. The generously oversized polished stainless steel front flange allows for easy retrofit installation.

Specifications:

Connection Location: Lower Mount
Wetted Parts: Brass Copper Alloy
Case Material: Forged Brass
Case Filling: Liquid
Window Type: Standard
Window Construction: Acrylic

Connection Size	7/16-20 SAE
Dial Material	White Aluminum
Media Operating Temperature	150°F Soldered, 212°F Brazed °F
Pointer Material	Black Aluminum
Case Material	Forged Brass
Manufacturers Part Number	9795090
Bezel Type	Cover Ring
Package Quantity	1
Ambient Operating Temperature Range	-4°F to 140°F °F
Bezel Material	Gold-Plated ABS Plastic
Accuracy	2.5 Percent °F
Dual Size	1
Connection Location	Lower Mount
Fillable	Yes
Window Material	Acrylic
Window Type	Standard
Wetted Parts Material	Brass Copper Alloy
Type	213.40
Factory Filling	Glycerine
Range	5,000 PSI
Gauge Size	2-1/2 in
Brand	Wika Instruments
